LIFT

AERIAL LIFT 34' 4X4RT


	Image for reference only Actual item may look different Click on image for larger view Click on above thumbnails for alternate view

4 Hour: $260.00

Daily: $300.00

Weekly: $825.00

Quantity: for a period of
4 hour(s) day(s) week(s)

Genie 4x4 Aerial Lift
Ideal for outdoor construction and industrial applications, the engine-powered Genie Z -34/22 IC articulating boom lift provides lifting versatility with a combination of up, out and over positioning capabilities and outreach that s second to none.
Working height maximum 40 ft 6 in
Platform height maximum 34 ft 6 in
Horizontal reach maximum 22 ft 3 in
Up and over clearance maximum 15 ft
Platform length 2 ft 6 in, Platform width 4 ft 8 in
Height - stowed 6 ft 7 in, Length - stowed 18 ft 6 in
Storage height 7 ft 5 in, Storage length 13 ft 5 in
Width 5 ft 8 in
Wheelbase 6 ft 2 in
Ground clearance - center 6 in
Productivity
Lift capacity 500 lb
Platform rotation 180 , Vertical jib rotation 139
Turntable rotation 355 , Turntable tailswing zero
Drive speed - stowed 3.0 mph, Drive speed - raised 0.68 mph
Gradeability - stowed 37%
Turning radius - inside 5 ft 9 in
Turning radius - outside 13 ft 1 in
26 hp (19.4 kW) Kubota diesel T4f D1105
Fuel tank capacity 9.0 gal
Weight 10,150 lb

* Prices are subject to change.

* Please call us if you have questions about our aerial lift 34 foot 4x4rt rentals in North Wilkesboro or Statesville NC.
